This server is equipped with a brand-new 8-GPU module (SXM & OAM). Its modular design greatly enhances overall heat dissipation and maintainability, enabling GPUs to deliver full performance. The compute unit supports up to 2 Intel® Xeon® 6 SP series processors. Paired with multi-channel DDR5 memory running at 6400 MT/s, it delivers up to 50% higher memory bandwidth. Featuring 11 PCIe 5.0 slots and a maximum of 18 drive bays, it accommodates diverse computing architecture solutions and further boosts system computing performance. It is ideal for high-computing scenarios including large-scale model training, High Performance Computing (HPC) and large-scale data centers.
| Model | X7980su V7 |
| GPU | Supports 8-GPU module (SXM & OAM) |
| Processor | Up to 2 Intel® Xeon® 6 SP series processors |
| 6700/6500 series: maximum 86 cores per processor, peak power 350W | |
| Memory | • Up to 32 DDR5 memory slots; speed up to 6400 MT/s with RDIMM, up to 8000 MT/s with MRDIMM |
| • Maximum capacity: 8 TB; supports CXL 2.0 | |
| Storage Expansion | Compatible with SAS/SATA/NVMe drives: |
| • Up to 18 x 2.5-inch drives (8 front SATA + 8 front NVMe + 2 rear NVMe) | |
| • Optional 2 x 2280 SATA/NVMe M.2 SSDs | |
| PCIe Expansion | Up to 4 PCIe 5.0 expansion slots: |
| • Up to 2 x16 + 1 x8 standard PCIe 5.0 slots (CPU) | |
| • 1 onboard OCP 3.0 slot | |
| Network | 8*CX8 800G direct-out ports (InfiniBand or Ethernet, PCIe 6.0) |
| Management Software | Integrated AST2600 BMC chip; supports IPMI 2.0, Redfish, SOL, KVM, Virtual Media and other functions |
| Security | Supports Intel PFR 3.0, SGX 2.0, TCM and TPM security modules |
| Cooling System | Air cooling |
| Fans | 20 fans with N+1 hot-swap redundancy |
| Power Supply | • 10 units of 3000W/3500W/5200W/5500W 54V Titanium power supplies |
| • 2 units of 1600W/2000W/2700W 12V Platinum power supplies or 3200W Titanium power supply | |
| • Supports N+N and N+1 redundancy | |
| Operating Temperature | 5°C ~ 35°C (The actual operating temperature range depends on configuration) |
| Form Factor & Dimensions | 10U |
|
• With mounting ears: 440 mm (H) × 447 mm (W) × 920 mm (D) • Without mounting ears: 440 mm (H) × 447 mm (W) × 890 mm (D) |
